PROGRESSIVE SUSPENSION 412 Series Shock - 12.5" - Standard - Black 412-4064B
$379.95
Skip to product information
In stock
Product videos
Progressive Suspension
PROGRESSIVE SUSPENSION 412 Series Shock - 12.5" - Standard - Black 412-4064B
412-4064B
$379.95
Fitment check
Does this fit your bike?
A saved-bike match is a shopping aid. Always review manufacturer notes, exclusions, measurements, and installation requirements.
412 Series Shock - 12.5" - Standard - Black
Features
- Designed specifically for Harley models
- The 412's simple, durable design makes them a cost effective improvement to your motorcycle's suspension performance
- A five position cam style spring load preload adjuster lets you easily dial in your ride
- Some or all shocks listed are approved for road use. Refer to most recent certificate for current listing
- There are multiple style options available, like full show-chrome or black covers; or either chrome or black springs and end caps
- Made in the USA
- All shocks are measured center-of-eyelet to center-of-eyelet.
- When installing shocks on '86-'15 XL models, it may be necessary to modify or space the chain/belt guard to allow proper clearance.
- A shock which is slightly longer than stock may alter the head angle slightly and provide somewhat quicker steering.
- A shock which is slightly shorter than stock may alter the head angle slightly and provide somewhat slower steering.
- Heavy Duty Applications are recommended for bikes that are operated at or near the manufacturer's maximum load rating over 50% of the time.
- Before purchasing or attempting to install shocks that are different than the OEM length, confirm that your wheel travel can be altered without causing clearance issues, such as swingarm/axle to exhaust contact as well as chain/belt guard or tire contact.
Specifications
- Adjustment Style: Automatic
- Color/Finish: Black
- Damping Method: Gas Charged
- Duty: Standard
- Extended Length: 12.50"
- Material: Steel
- Model: 412 Series without Covers
- Mounting Position: Rear
- Product Name: Shock Absorber
- Progressive Spring Rate: 1.35 kg/mm - 2.15 kg/mm
- Reservoir Location: Internal
- Riding Style: Street
- Spring Type: Single Progressive Rate
- Type: Coilover Monotube
- Units: Pair
- Country of Origin: MX
- Package Dimensions: 16.92 L × 6.7 W × 3.34 H in
- Shipping Weight: 9.46 lb
California Proposition 65 warning applies.
Manufacturer fitment
Fits
- Harley-Davidson 1200 Custom EFI XLC, 2004-2006.
- Harley-Davidson 1200 Low EFI XLL, 2006.
- Harley-Davidson 1200 Roadster EFI XLR, 2006.
- Harley-Davidson 1200 XLCP, 2011-2017.
- Harley-Davidson 883 Custom EFI XLC, 2004-2006.
- Harley-Davidson 883 EFI XL, 2009.
- Harley-Davidson 883 Low EFI XLL, 2006.
- Harley-Davidson 883 Roadster EFI XLR, 2005-2006.
- Harley-Davidson 883 Roadster XLR, 2007.
- Harley-Davidson Sportster 1200 X XR, 2009.
- Harley-Davidson Sportster 1200 XR, 2011-2012.
- Harley-Davidson XL1200C Sportster 1200 Custom, 2004-2019.
- Harley-Davidson XL1200CX Roadster, 2016-2020.
- Harley-Davidson XL1200L Sportster 1200 Low, 2006-2011.
- Harley-Davidson XL1200N Sportster 1200 Nightster, 2007-2012.
- Harley-Davidson XL1200NS Iron 1200, 2018-2021.
- Harley-Davidson XL1200R Sportster 1200 Roadster, 2004-2009.
- Harley-Davidson XL1200T SuperLow 1200T, 2014-2017.
- Harley-Davidson XL1200V Seventy-Two, 2012-2016.
- Harley-Davidson XL1200X Forty-Eight, 2010-2022.
- Harley-Davidson XL1200XS Forty-Eight Special, 2018-2019.
- Harley-Davidson XL50 50th Anniversary Sportster, 2007.
- Harley-Davidson XL883 Sportster, 2004-2008.
- Harley-Davidson XL883C Sportster 883 Custom, 2004-2009.
- Harley-Davidson XL883L Sportster 883 Low, 2005-2010.
- Harley-Davidson XL883L SuperLow, 2011-2019.
- Harley-Davidson XL883N Iron 883, 2009-2022.
- Harley-Davidson XL883R Sportster 883 Roadster, 2005-2007.
- Harley-Davidson XR1200, 2010.
- Harley-Davidson XR1200X, 2010-2012.
